Gladiator Wheel Portable Crushing & Screening Equipment

The Powerscreen® Gladiator™ range is a new range of wheeled crushing & screening plants that is easy to transport and operate, reliable and environmentally friendly.

Gladiator Wheel Portable Crushing & Screening Equipment

The Powerscreen® Gladiator™ range is a new range of wheeled crushing & screening plants that is easy to transport and operate, reliable and environmentally friendly.

Gladiator Wheel Portable Crushing & Screening Equipment

The Powerscreen® Gladiator™ range is a new range of wheeled crushing & screening plants that is easy to transport and operate, reliable and environmentally friendly.

powerscreen-gladiator-teaser-image

The most reliable portable crushing equipment, from the most trusted mobile manufacturer.

The Gladiator range of wheel portable crushing and screening equipment combines the field-proven efficiency and durability of Powerscreen crushers and sceenboxes with the simplicity and flexibility of wheeled portable equipment.

The range is fully electrically driven using tried and tested Powerscreen® Hybrid™ technology, making it an ideal choice in locations with strict environmental regulations.




Rugged & Dependable
Field-proven crushing & screening technology


Easy to Operate
Fast set-up & easy to use, simple push-button controls


Fully Electric Driven
Powerscreen Hybrid Technology


Modular Units
Maximum versatility to work in multiple configurations

Gladiator PT400 Jaw Crusher

The Gladiator PT400 is a new electrically driven, wheeled jaw crusher. It features the tried-and-tested JW42 jaw crushing chamber and is chassis mounted on wheels meaning ease of movement and set-up.

Specifications

Output: Up to 463 US tph (420 tph)

Transport Dimensions
Width: 11′ 3″ Length: 52′ 3″ Height: 13′ 7″

Working Dimensions
Width: 11′ 3″ Length: 52′ 3″ Height: 15′ 9″

Weight 96,200 lbs

CSS Range Min: 1.75″ Max: 5.75″

Gladiator MT1150 Cone Crusher

The Gladiator MT1150 is a new electrically driven, wheeled open circuit cone crusher. It features the tried-and-tested Terex® TC1150 cone chamber and is chassis mounted on wheels meaning ease of movement and set-up.

 Specifications

Output: Up to 330 US tph (300 pth)

Transport Dimensions
Width: 11′ 11″ Length: 47′ 5″ Height: 13′ 2″

Working Dimensions
Width: 11′ 11″ Length: 47′ 5″ Height: 13′ 2″

Weight 68, 530lbs

Gladiator MT1150SR Cone Crusher

The Gladiator MT1150SR is a wheeled, electric drive closed-circuit cone crushing/screening plant.

Specifications

Output: Up to 496 US tph (450tph) *application dependant

Transport Dimensions
Width: 12′ 9.5″ Length: 62′ 4″ Height: 13′ 11.5″

Working Dimensions
Width: 12′ 9.5″ Length: 62′ 4″ Height: 15′

Weight 115,000lbs

Gladiator H6203 6’ x 20’ 3-Seck Horizontal Screen

The Gladiator H6203 is a new, electrically driven, wheeled horizontal screening plant which offers excellent screening and blending capabilities.

Specifications

Output: Up to 881 US tph (800 tph)

Transport Dimensions
Width: 12′ Length: 42′ 2″ Height: 13′ 6″

Working Dimensions
Width: 12′ Length: 42′ 2″ Height: 13′ 6″

Weight 54,250lbs

Screen 20′ x 6′ 4″ (All 3 Decks)

Gladiator TP320SR Closed Circuit Impact Crusher

The Gladiator TP320SR Closed Circuit Impact Crusher is a new hybrid-electric drive, wheeled, closed-circuit impact crusher. This portable closed-circuit crushing and screening plant combines the might of the Trakpactor 320 impact crusher with the Chieftain 1700 2 deck inclined screen for recirculation.

Specifications

Output: Up to 353 US tph (320tph)

Transport Dimensions:
Width: 11′ 10 Length: 69′ Height: 13′ 5″

Working Dimensions
Width: 18′ 11″ Length: 68′ 10″ Height: 16′ 6″

Weight 94,006 lbs

CSS Range Min Lower: 0.75″ Max Lower: 2″ Min Upper: 2.9″ Max Upper: 6″

Click the image below to download the Gladiator full lineup brochure.
powerscreen-gladiator-brochure
